BTS DYNAMITE 21339 LIGHT KIT INSTALL GUIDE
17
NOTE
Keep the following cable
positioned as shown while
twisting the cables below
NOTE
Keep the following cable
positioned as shown while
concealing the board and
cables
NOTE
Conceal the IR Board and cables but
exclude the 5cm Connecting Cable
Also ensure to position the port with
the 5cm Connecting Cable on the left
side
NOTE
Exclude the 5cm Connecting
Cable when twisting the cables
NOTE
Pull the indicated cables down
into the gap tightly
To Next Page
