Light4Me HYPNO PAR - Photometric Diagram

LIGHT4ME HYPNO PAR
Instrukcja obsługi / User Manual
15
 Input voltage: AC90-260V 50-60Hz
 Power consumption: 20W
 Control signal: DMX512, master-slave and sound activated
 Control channel: 24/12 DMX Channels DMX-512
 Dimensions (D x W x H): 26,5 x 21,4 x 11,7 cm
 Net Weight: 1,5 kg
Features:
 50,000 hours life span and low power consumption
 Engineering grade nylon plastic, flame retardant
and corrosion resistant
 Cooling system
 Built-in programs that could be called up via
a DMX controller
 25t/s strobe effect and pulse strobe effect
 0-100% electronic dimming
 4-button LED display on rear panel
 Powercon connector in/out
 3-pin XLR connectors in/out
 Overheat protection
 45ºC max ambient temperature
Photometric diagram
