Light4Me THUNDER BAR - Features; Control; Menu Display Instruction

ENGLISH
Features
Voltage: AC100-240V 50/60Hz
Switching power supply: 12V/100W
Light source: 12* 3W 3535 warm white LED+ 156pcs 5730 led+ 96pcs 5050RGB LED;
operation modes: Automatic running, DMX512, Sound Active, Master/Slave
Sound controlled via built-in microphone
Beam angle: 6 degrees, radiation range: 8 degrees;
Dimming frequency: FLICKER FREE Up to 10KHz dimming refresh PWM frequency, camera shooting
without flicker.
0-100 linear dimmer, high power led and low power consumption
5CH/14CH /62CH DMX channels selectable
Packing Size:
Weight: 3.5kg
Control
Menu display Instruction
DMX address
ADDR
DMX address (0-512)
Channel mode
CHND
5CH/ 14CH/62CH
Master/Slave
/d512
Mode
Mast
DMX512
Slave
Sound mode
SOUN
Sound 0--sound 59
SENS 0--100
AUTO
AUTO
AUTO 0-59
Speed 0--9
COLOR
COLO
color1--color15
Display inversion
DISP
inversion
Software version
Ver
V12
