Lightmaxx Cannon Shot FX FOUR - Connections and Controls Overview; Device Connectors and Indicators; Controls and Interfaces

ENGLISH
Connections and controls:
No. Designation No. Designation
1 Cannon screw nut 7 DMX-Output (3-pol)
2 Richt screw nut 8 Display and Menu buttons
3 Cannon tube 9 PowerCon Input
4 Cannon connector 10 Safety
5 LED indicator 11 Receiver connection
6 DMX-Input (3-pol) 12 On-/offswitch
1
2
3
4
5
6
7
8
9
10
11
12
