Lightmaxx Cannon Shot FX TWO - Device Layout and Controls; Component Identification

ENGLISH
Connections and controls:
No.
Designation
No.
Designation
1
Cannon screw nut
7
DMX-Output (3-pol)
2
Richt screw nut
8
Display and Menu buttons
3
Cannon tube
9
PowerCon Input
4
Cannon connector
10
Safety
5 LED indicator 11 Receiver connection
6
DMX-Input (3-pol)
12
On-/offswitch
1
2
3
4
5
6
7
8
9
10
11
12
