Channel Value Function
1 0-255 Dimmer
2
0-255 Strobe
3
0-255
Macro
4
0-255
Macro Speed
5
0-255
Red Dimmer
6
0-255
Green Dimmer
7
0-255
Blue Dimmer
8
0-255
White Dimmer
9
*
0-255
Amber Dimmer
DEUTSCHENGLISH
* only with VEGA Silent PAR I / II Complete
Resistance 120 ohm // 1/4 W between pin 2 /DMX-) and pin 3 (DMX+) of the last fi xture.
Operating mode DMX:
Connect the DMX input of your device to the DMX output of your DMX controller, your DMX soft-
ware or the DMX output of a device already in your DMX line. Always use a DMX cable with a 110
Ohm resistor for this connection. Address the device accordin
g to your DMX confi guration. The
following table shows the respective DMX modes of the individual devices with the corresponding
values and functions:
VEGA Silent PAR I/II/Quad (8 channel mode/9 channel mode)
Commissioning:
Make sure everything is plugged in before switching on. Only use high-quality, preferably short cables.
Confi guration of the DMX connector (3 pin):
