ENGLISH
Operating mode DMX:
Connect the DMX input of your device to the DMX output of your DMX controller, your DMX
software or the DMX output of a device already in your DMX line. Always use a DMX cable with a
110 Ohm resistor for this connection. Address the device according to your DMX configuration.
The following table shows the respective DMX modes of the individual devices with the
corresponding values and functions:
2 Channel-Mode:
6 Channel-Mode:
Channel
Value
Function
1
0
Dimmer Close
001-255
Dimmer
(dark to bright)
2
001-004
Strobe Speed Close
000-255
Strobe Speed
(slow to fast)
Channel
Value
Function
1
000-004
Brightness Close
005-255
Dimmer
(dark to light)
2
000-004
One fourth Brightness Close
005-255
One fourth Dimmer
(dark to bright)
3
000-004
One fourth Dimmer Close
005-255
One fourth Dimmer
(dark to bright)
4
000-004
One fourth Dimmer Close
005-255
One fourth Dimmer
(dark to bright)
5
000-004
One fourth Dimmer Close
005-255
One fourth Dimmer
(dark to bright)
6
001-004
Strobe Speed Close
000-255
Strobe Speed
(slow to fast)
