Lilytech ZL-6 A-R Series User Manual

1:Enable
13 U36
Defrost delay time when the device
start
0～180min
0: Disable 0
14 U50
High-temperature warning deviation
value to Max Temp
0~60℃ 0: Disable 0
15 U51
Low-temperature warning deviation
value to Min Temp
0~60℃ 0: Disable 0
16 U52
Over-temperature warning delay
time
1～180min
30
17 U53
First over-temperature warning
delay time after power supply
0~180 hour 0: Disable 2
18 U60 External input warning mode 0~4
0:Warning off
1:On, Lock
2:On, Unlock
3:Off, Lock
4:Off, Unlock
0
19 U61
External warning input delay
0~120min 0
20 U62 Buzzer warning 0~1
0:Warning off
1:Warning on
21 U97 Baud rate setting 0 ~ 3
0: 2400bps
1: 4800bps
2: 9600bps
3: 19200bps
3
22 U98 Device address 1 ~ 99 ---- 1
23 U99 Password 0000~9999 1111
24 End Finished setting
ZL-630A-R:
No
Parameter
code
Function Range Note
Factory
setting
1 U10 Compressor power on delay time
1～100min
3
2 U11
Compressor MIN continuous work
time
0～100min
3
3 U12 Compressor run frequency
0～8
0: Disable 5
4 U20 Room temperature sensor calibration
-9.9～+9.9
0
5 U21 Defrosting sensor calibration -9.9~+9.9 0
6 U22 Temperature difference
0.1～+10.0℃
The hysteresis
of control
1.0
7 U30 Defrosting cycle 0~180 hour 0: Not defrost 12
8 U31
Defrosting﹙end﹚time 1～180min
30
9 U32 Defrosting end temperature
0.5～50℃
15
