13
3. Turn on the electrical equipment to measure the moment start up current. The
meter is locked to the highest measurement range.
4. Press select button for 1 second to exit surge current mode.
Resistance measurement (See fig 1)
1. Insert red test lead into the VHz terminal and black test lead into the COM
terminal.
2. Set the rotary switch to position.
3. Push select button to select resistance function. Displays shows .
4. Connect the test leads across with the object being measured. The measured
value shows on the display.
Note
• The test leads can add 0.1 to 0.3 of error to resistance measurement. To
obtain precision readings in low-resistance measurement, that is the range of
200, short-circuit the input terminals beforehand and record the reading
obtained. This is the additional resistance from the test lead.
• OL displays when the circuit is open or the resistor value is higher than max
range.
Frequency and Duty Cycle measurement (See fig 2)
1. Insert red test lead into the VHz terminal and black test lead into the COM
terminal.
