LIMIT DM 620 - Electrical Specifications: AC Voltage; Electrical Specifications: Resistance; Electrical Specifications: Continuity and Diode

17
• Frequency measurement range: 40 Hz~1 kHz, input amplitude:
≥
10% of voltage range. Duty ratio is
for reference only
• Accuracy guarantee: 2%~100% of 60 mV range, 1 %~100% of other ranges; short circuit allows least
significant digit
≤
3
• Max input voltage: 1000 V (if the voltage is >1000 V the red indicator light will be on and the buzzer
will sound an alarm; if the voltage is >1010 V, the LCD will display “OL”)
• Overload protection: 1000 V
3. Resistance
Range Resolution Accuracy
600.0
Ω
0.1
Ω
± (1.2%+2)
6.000 k
Ω
1
Ω
± (1.0%+2)60.00 k
Ω
10
Ω
600.0 k
Ω
100
Ω
6.000 M
Ω
1 k
Ω
± (1.2%+2)
60.00 M
Ω
10 k
Ω
± (2.0%+5)
• Measurement result = displayed value - resistance of shorted test leads
• Open-circuit voltage: About 1 V
• Accuracy guarantee: 1%~100% of range
• Overload protection: 1000 V
4. Continuity and diode
Range Resolution Remarks
0.1
Ω
Broken circuit: Resistance
≥
70
Ω
, no beep. Good continuity:
Resistance <50
Ω
, audio/visual alarm.
0.001 V
Open-circuit voltage: About 3V.
For normal diodes, the buzzer will beep once.
For short circuit, the buzzer will beep for a long time.
• Overload protection: 1000 V
• When the forward voltage drop is within 0.12~2 V, the buzzer will beep once.
When the forward voltage drop is <0.12 V, the buzzer will beep for a long time.
5. Capacitance
Range Resolution Accuracy
60.00 nF 10 pF
± (3%+5)
600.0 nF 100 pF
6.000
μ
F 1 nF
60.00
μ
F 10 nF
600.0
μ
F 100 nF
6.000 mF 1
μ
F
± (10%+5)
60.00 mF 10
μ
F
• Overload protection: 1000 V
• Measurement result = Displayed value - capacitance of open-circuit test leads
