18
• For capacitance
≤
1
μ
F, it is recommended to use the REL mode to deduct the open-circuit reading
• Accuracy guarantee: 1~100% of range
• For ranges of 60 mF. the measurement time is about 20 s
6. Temperature
Range Resolution Accuracy
-40~1000°C
-40~0°C
0.1°C~1°C
± (1.0%+30°C)
0~300°C ± (1.0%+20°C)
300~1000°C ± (1.0%+3°C)
-40~1832°F
-40~32°F
0.2°F~2°F
± (1.0%+60°F)
32~572°F ± (1.0%+40°F)
572~1832°F ± (1.0%+6°F)
• The measured temperature should be less than 230°C/446°F
7. DC current
Range Resolution Accuracy
600.0
μ
A 0.1
μ
A
± (1.0%+2)
6000
μ
A 1
μ
A
60.00 mA 10
μ
A
± (1.0%+3)
600.0 mA 0.1 mA
6.000 A 1 mA
± (1.2%+5)
20.00 A 10 mA
• Overload protection:
mA/
μ
A range: F1 Fuse 600 mA 1000 V
Ф
6 × 32 mm.
A range: F2 Fuse 11 A 1000 V
Ф
10 × 38 mm
• Open circuit allows least significant digit
≤
5
• Accuracy guarantee: 1~100% of range
8. AC current
Range Resolution Accuracy
600.0
μ
A 0.1
μ
A
± (1.2%+5)
6000
μ
A 1
μ
A
60.00 mA 10
μ
A
± (1.5%+5)
600.0 mA 0.1 mA
6.000 A 1 mA
± (2.0%+5)
20.00 A 10 mA
• Display: True RMS
• Frequency response: 40 Hz ~ 1 kHz
• Accuracy guarantee: 5~100% of 600.0
μ
A range.
1~100% of other ranges; open circuit allows least significant digit
≤
5
• The AC crest factor can be
≤
3.0 at 3000 counts, and can only be
≤
1.5 at 6000 counts. The additional
error should be added according to the crest factor of a non-sinusoidal wave, as follows:
a. Add 4% when crest factor is 1~2
b. Add 5% when crest factor is 2~2.5
