LINCHR E-Series - Page 4

E-series AC Charger
Configuration manual V1.3 3
Basic electrical information
Model
ES-07-B
ES-07-C
ES-22-B
ES-22-C
Rated power
7KW(Single
phase)
7KW(Single
phase)
22KW(Three
phase)
22KW(Three
phase)
Connection
mode
Socket(IEC
62196-2)
Cable-5m(IEC
62196-2)
Socket(IEC
62196-2)
Cable-5m(IEC
62196-2)
Grid system
TN-S,TN-C-
S,TT,IT
TN-S,TN-C-
S,TT,IT
TN-S,TN-C-
S,TT
TN-S,TN-C-
S,TT
Power supply
system
1P+N+PE or
2P+PE
1P+N+PE or
2P+PE
3P+N+PE
3P+N+PE
Rated voltage
230VAC
230VAC
400VAC
400VAC
Voltage range
196~264 VAC
196~264 VAC
380~415VAC
380~415VAC
Rated output
current
32A
32A
32A
32A
Frequency
Range
50 Hz±1%/60
Hz±1%
50 Hz±1%/60
Hz±1%
50 Hz±1%/60
Hz±1%
50 Hz±1%/60
Hz±1%
Ambient
temperature
-25℃～+50℃
-25℃～+50℃
-25℃～+50℃
-25℃～+50℃
Storage
temperature
-40～+70℃
-40～+70℃
-40～+70℃
-40～+70℃
Protection level
IP54
IP54
IP54
IP54
Standby power
＜15W
＜15W
＜15W
＜15W
Relative
humidity of use
environment
≤95%
≤95%
≤95%
≤95%
