Lincoln 2006 Zephyr User Manual

Fuse/Relay
Location
Fuse Amp
Rating
Passenger Compartment Fuse
Panel Description
12 7.5A Delay accessories: Radio head
units, Moonroof, Front power
windows, Electrochromatic
mirrors
13 7.5A Cluster, KAM-PCM, Analog clock,
Climate control head units,
Canister vent solenoid
14 15A Washer pump
15 20A Cigar lighter
16 15A Door lock actuator, Decklid lock
solenoid
17 20A Subwoofer, THXII DSP module
18 20A Radio head units, OBDII
connector
19 — Not used
20 7.5A Power mirrors, DSP
(THX/Navigation radio)
21 7.5A Stop lamps
22 7.5A Audio
23 7.5A Wiper relay coil, Cluster logic
24 7.5A OCS (Passenger’s seat), PAD
indicator
25 7.5A RCM
26 7.5A PATS Transceiver, Brake shift
interlock solenoid, Brake pedal
switch
27 7.5A Cluster, Climate control head
units
28 10A ABS/Traction Control, Heated
seats, Compass
C/B 30A Circuit
Breaker
Rear p ower windows, Delayed
accessory (SJB fuse12)
2006 Zephyr (378)
Owners Guide (post-2002-fmt)
USA (fus)
