Lincoln 2006 Zephyr User Manual

Fuse/Relay
Location
Fuse Amp
Rating
Power Distribution Box
Description
6 40A** Rear window defroster, Heated
mirrors
7 — Not used
8 — Not used
9 20A** Wipers
10 20A** ABS Valves
11 30A** Heated seats, Passenger
heated/cooled seat
12 30A** Driver heated/cooled seat
13 — Not used
14 15A* Ignition switch
15 10A* Memory module logic
16 15A* Transmission
17 20A* Console power point
18 10A* Alternator sense
19 40A** Logic feed to SJB (solid state
devices)
20 20A** THXII Amplifier #1
21 20A** THXII Amplifier #2
22 — Not used
23 60A** SJB power feed (fuses 1, 2, 4, 10,
11)
24 15A* Fog lamps
25 10A* A/C Compressor clutch
26 15A* LH HID Low beam
27 15A* RH HID Low beam
28 — Not used
29 60A*** Engine cooling fan
30 30A** Fuel pump relay feed
31 30A** Passenger power seat
32 30A** Driver power seat
33 20A** Moonroof
2006 Zephyr (378)
Owners Guide (post-2002-fmt)
USA (fus)
