Page Number - 2
Form 403175
FAILURE TO HEED THE FOLLOWING WARNINGS INCLUDING MISUSE, OVER PRESSURIZING, MODIFYING PARTS,
USING INCOMPATIBLE CHEMICALS AND FLUIDS, OR USING WORN OR DAMAGED PARTS, MAY RESULT IN EQUIPMENT
DAMAGE AND/OR SERIOUS PERSONAL INJURY, FIRE, EXPLOSION, OR PROPERTY DAMAGE.
· Do not exceed the stated maximum working pressure of the reel or of the lowest rated component in your system.
· Do not alter or modify any part of this equipment.
· Do not operate this equipment with combustible gas.
· Do not attempt to repair or disassemble the equipment while the system is pressurized.
· Make sure all fluid connections are securely tightened before using this equipment.
· Always read and follow the fluid manufacturers recommendations regarding fluid compatibility, and the use of protective
clothing and equipment.
· Check all equipment regularly and repair or replace worn or damaged parts immediately.
· Never point the dispensing valve at any part of the body or at another person.
· Never try to stop or deflect material from dispensing valve or leading connection or component with your hand or body.
· Always check equipment for proper operation before each use, making sure safety devices are in place and operating
properly.
· Always follow the pressure relief procedure after shutting off the pump, when checking or servicing any part of the system,
and when installing cleaning or changing any part of the system.
ASSEMBLY
Assemble reel as follows. Refer to SERVICE PARTS for part
numbers and location.
A. Assemble arbor and ratchet casting (237670) to
support assembly (237656) with four hex head
screws (50014) and four hex nuts 51022).
B. Lubricate V-ring seal (237671) and place on arbor
and ratchet casting (237670) with lip facing away
from arbor ratchet.
C. Assemble power spring assembly (248493) onto
arbor and ratchet casting (237670) until spring
canister bottoms on arbors shoulder
D. Lubricate V-ring seal (237673) and assemble onto
arbor and ratchet casting (237670) with lip facing
toward spring canister.
E. Assemble axle (237675) to sheave assembly
(237680) with three nuts (51010).
F. Assemble axle and sheave assembly to reel by
sliding axle (237675) through bearings in the arbor
and ratchet casting (237670). Secure with washer
(48217) and TRU-ARC (68424). Shim as required
using shims (48385) between washer (48217) and
arbor and ratchet casting (237670) to eliminate axle
end play.
G. Rotate sheave assembly (237680) and align six
mounting holes with mating holes in power spring
cannister (248493). Secure with five carriage bolts
(237738). carriage bolt (237739) and six nuts
(51010).
NOTE:The carriage bolt (237739) is assembled in
hole adjacent to pawl pin.
H. Assemble roller outlet arm assembly (237690) on
bolts (5O014) and secure using three nuts (51022).
I. Assemble roller outlet assembly (237692) to roller
outlet arm, assembly (237690) by snapping into
stamped out contour in roller arm. Make certain that
snap-locks are firmly seated after assembling.
J. Assemble swivel assembly (237684) in axle
(237675) and tighten.
K. Assemble inlet adapter (237686) into swivel
assembly (237684) and secure with U-keeper
(15674).
L. Lubricate O-Ring (261187) and back-up ring
(260389) and assemble into axle (237675).
M. Assemble outlet adapter (237678) into ax!e
(237675). Secure with U-keeper (15674).
