Line 6 POD Studio UX2 User Manual

MIDI Setup Guide: MIDI Control Configuration
2•1
MIDI ConTrol ConfIguraTIon
In this chapter we’ll show how to configure the specific type of MIDI messages your POD Studio™/
TonePort™ controllers transmit when you access them. This is all accomplished using the Line 6
MIDI Control Settings dialog, where you can view these settings, as well as create and save your own
customized preset control mappings to load any time.
Default MIDI Control Settings
UX2, UX8 & KB37 ship with a default set of MIDI Control Messages assigned to their controllers,
as shown in the handy table below. Your device will send these MIDI commands right “out of the
box”, without any further configuration needed. Note that by default your Line 6 device sends out two
different sets of MIDI messages - one set is transmitted directly to the Line 6 GearBox™ application
(if launched), and the other transmitted to the POD Studio/TonePort USB MIDI Out port. MIDI data
transmitted out the USB MIDI Out port are the ones you’ll be sending to POD Farm™ 2 and other
software.
There are a number of preset “Controller Mappings” available for you to select from within the Line 6
Audio-MIDI Devices dialog. The GearBox & MIDI Default preset is the one initially loaded for your
device. This preset consists of the following settings. Note that the GearBox Parameter column lists
what the specific GearBox action will be, while the MIDI Message column lists what is transmitted to
the USB MIDI Out port:
GearBox & MIDI Default Preset Assignments
POD Studio/
TonePort Model
Switch/Controller
Name
GearBox Parameter MIDI Message
KB37 Modulation wheel (No Assignment) CC 001 Mod Wheel
KB37 Sound Select (Previous) Next Tone Preset Program Change –1
KB37 Sound Select (Next) Previous Tone Preset Program Change +1
KB37 Knob 1 Amp – Drive CC 073 (Attack Time)
KB37 Knob 2 Amp – Bass CC 075 (Decay Time)
KB37 Knob 3 Amp – Middle CC 072 (Release Time)
KB37 Knob 4 Amp – Treble CC 091 (Effects 1 Depth)
KB37 Button 1 Stomp – toggle on/off CC 065 (Portamento)
KB37 Button 2 Mod – toggle on/off CC 127 (Poly On)
KB37 Button 3 Delay – toggle on/off CC 126 (Mono On)
KB37 Button 4 Reverb – toggle on/off CC 123 (All Notes Off)
KB37 Stop Stop MMC Stop
KB37 Play Play MMC Play
KB37 Record Loop MMC Record Punch
KB37 Rewind Rewind MMC Rewind
