Line 6 POD Studio UX2 User Manual

MIDI Setup Guide: MIDI Control Configuration
2•2
POD Studio/
TonePort Model
Switch/Controller
Name
GearBox Parameter MIDI Message
KB37 Forward Forward MMC Fast Forward
KB37, UX8 Expression Pedal Wah CC 11 (Expression)
KB37. UX8,
UX2
Footswitch 1 Stomp – toggle on/off CC 64 (Sustain)
KB37. UX8,
UX2
Footswitch 2 Tuner MMC Record Punch
Choosing a Controller Mapping Preset
In addition to the default GearBox and MIDI Default preset described above, there are also several
presets for specific MIDI/DAW software applications as well. You can select one of these presets from
the Controller Mapping menu within the Line 6 Audio-MIDI Devices dialog:
• Windows
®
- Control Panel > Line 6 Audio-MIDI Devices > MIDI tab
• Mac
®
- System Preferences > Line 6 Audio-MIDI Devices > MIDI tab
Please see the following chapters for more information regarding the 3rd party application presets. To
see and edit the individual controller settings, you can launch the MIDI Control Settings dialog, as
explained in the next section.
Note: There is not a preset for POD Farm 2 control, however, we’ve provided a set for you to configure in
“Recommended MIDI Control Settings for POD Farm 2” on page 5•1.
