QUICK START GUIDE FOR DEMONSTRATION CIRCUIT 600
EVALUATION CARD FOR THE LTC1540 IN THE DFN PACKAGE
QUICK START PROCEDURE
Build the evaluation circuit in one of two ways as shown in Figures 1 and 2.
C3
R3
C1
C2
R1
R2
R4
C4
E
OUT
GND
E
IN
GND
V
CC
GND
V
EE
LA xx
Figure 1.
External Components Directly on the PCB (0.1•F Bypass Capacitors: AVX 1206C104KAT). Example connections shown may not
be correct for this device.
GROUND WIRE
FOR BYPASS CAPS
DFN
PACKAGE
TEST
BOARD
DEMONSTRATION
CIRCUIT
8-PIN DIP
SOCKET
HEADER: MILL-MAX
3402-0-00-21-00-00-03-0
Figure 2.
Convert the Board to an 8-pin DIP Format
2
