Linear Encore! - System Components; ENC-HUB System Hub; ENC-PS Power Supply; ENC-DRS Keypad

3
System Components
ENC-HUB
System Hub
Pure digital audio delivers crystal clear •
sound to all zones with no signal loss
Four speaker zones•
Expandable to 32 speaker zones•
Cat-5 wiring•
Mounts in structured wiring •
enclosure or on H275 bracket
Four high power terminals •
for long keypad runs
ENC-PS
Power Supply
120 VAC input, 26 VDC •
@ 8 Amp output
Output cable has connector for hub•
Green power indicator•
Mounts in structured wiring •
enclosure or on H275 bracket
ENC-DRS
Keypad
Controls speaker zone’s volume, •
tone, balance, and loudness
Integrated Class D digital amplifi er•
Built-in IR receiver for IR remote •
control of source components
Blue LED backlit buttons•
White keypad bezel and faceplate•
ENC-SIWP
Source Input Wall Plate
Stereo analog audio inputs•
Coaxial digital and SPDIF •
optical digital audio inputs
High quality analog-to-digital converter•
IR emitter output•
ENC-LIWP
Local Input Wall Plate
Coaxial digital and SPDIF •
optical digital audio inputs
Two stereo analog audio inputs•
High quality analog-to-digital converter•
IR emitter output•
ENC-REM
Basic Remote Control
Miniature size•
Selects audio source•
Adjusts speaker volume •
and has mute function
Remotely controls system power•
ENC-LRM
Learning Remote Control
Remote can learn codes from •
other remotes, providing ability
to control source components
from a remote location
Selects audio source•
Adjusts speaker volume •
and has mute function
Remotely controls system power•
Programmable macros with •
up to 19 steps each
ENC-DRSFA-SL-4
Screwless Faceplate Kit
(4-pack) (Almond)
Four almond keypad bezels•
Four almond screwless faceplates•
Changes keypad color or replaces •
damaged or worn faceplate
For ENC-DRS keypad•
ENC-DRSFB-SL-4
Screwless Faceplate Kit
(4-pack) (Black)
Four black keypad bezels•
Four black screwless faceplates•
Changes keypad color or replaces •
damaged or worn faceplate
For ENC-DRS keypad•
ENC-DRSFW4
Faceplate Kit
(4-pack) (White)
Four white keypad bezels•
Four white faceplates•
Includes matching plate screws•
For changing color or replacing •
damaged or worn faceplates
For ENC-DRS keypad, ENC-SIWP •
and ENC-LIWP input plates.
ENC-DRSFB4
Faceplate Kit
(4-pack) (Black)
Four black keypad bezels•
Four black faceplates•
Includes matching plate screws•
For changing color or replacing •
damaged or worn faceplates
For ENC-DRS keypad.•
ENC-DRSFA4
Faceplate Kit
(4-pack) (Almond)
Four almond keypad bezels•
Four almond faceplates•
Includes matching plate screws•
For changing color or replacing •
damaged or worn faceplates
For ENC-DRS keypad.•
2171-4
Single-head IR Emitter
(4-pack)
Single-head IR emitter, 4-pack•
Repeats IR signals from keypads •
to source components
Ten foot cord with mini plug•
Adhesive back on emitter•
