SWR • SWC • SWD Swing Gate Operator Installation Guide - 22 - 227965 Revision X22 8-11-2011
Photoeye Installation Illustration
SEPARATE PEDESTRIAN GATE REQUIRED
7 FT. MINIMUM DISTANCE AWAY FROM GATE
OBSTRUCTION DETECTING APPLICATION
(WIRE TO CLOSE OBSTRUCTION)
OBSTRUCTION DETECTING APPLICATION
(WIRE TO OPEN OBSTRUCTION)
PHOTOEYE REVERSE APPLICATION (WIRE TO REVERSE)
BEAM PATH
BEAM PATH
BEAM PATH
THIS DRAWING IS INTENDED TO DRAW ATTENTION
TO POSSIBLE LOCATIONS FOR THE INSTALLATION
OF CONTACT OR NON-CONTACT OBSTRUCTION SENSING DEVICES. OTHER AREAS OF ENTRAPMENT
MAY EXIST DEPENDING ON EACH SPECIFIC INSTALLATION.
CARE MUST BE TAKEN TO POSITION PHOTOEYES
SO THAT NUISANCE TRIPPING IS MINIMIZED.
REFER TO CONNECTION ILLUSTRATIONS FOR DETAILS

Linear SWC Specifications

General

Brand	Linear
Model	SWC
Category	Gate Opener
Language	English
