CHAPTER 4 FINAL DRIVE LH50DU SERVICE MANUAL 19.1
CHAPTER 4 FINAL DRIVE. 4-
24
8. Mount the Input Gear A and Mid Gear Shaft B and Diff Case Assembly C and Clutch Gear D
and Coupler E and Nut F.
→Fig 18
PS: Apply Loctite 271 evenly on the Bolt F screw thread. Tighten the Bolt to a torque of 80~90Nm
Fig 18
9. Mount the three Socket Head Bolts A and six Bolts B and Left Case C.
PS: Apply Loctite sealant 510 evenly on the surface of the seal.
→Fig 19
Fig 19
