CHAPTER5 BRAKES LH50DU SERVICE MANUAL19.1
CHAPTER 5 BRAKES PAGE. 5-
2
5.1 SPECIFICATIONS
Front Brake Caliper
Item
Standard
Service Limit
Brake Pad Friction material
Thickness
0.157"/ 4mm
0.04"/ 1mm
B rake Disc Thickness
0.150- 0.164"/3.810- 4.166mm
0.140"/ 3.556mm
Brake Disc Thickness Variance
Between Measurements
-
0.002 "/ .051m m
Brake Disc Runout
-
0.005 "/ .127mm
Rear Brake Caliper
Item
Standard
Service Limit
hydraulic
0.157"/ 4mm
Hydraulic with
mechanics park
0.236"/ 6mm
Brake Pad
Friction
material
Thickness
mechanics park
0.197"/ 5mm
0.04"/ 1mm
Brake Disc Thickness
0.177-0.187"/4.496-4.750m m
0.167"/4.242mm
Brake Disc Thickness
Variance
Between Measurements
-
0.002 "/ 0.051mm
Brake Disc Run out
-
0.005 "/ 0.127mm
5.2 TORQUE
Item
Torque
(ft. lbs. except where noted*)
Torque
(Nm )
Front Caliper Mounting Bolts
18.0
25
Rear Caliper Mounting Bolts
18.0
25
Front Brake Disc
18.0
25
Rear Brake Disc
18.0
25
Park Brake Mouting Bolts
35
47
Banjo Bolt
15.0
21
5.3 BRAKE SYSTEM SERVICE NOTES
 It is strongly recommended always change the caliper and (or) the master cylinder as an
assembly. The parts inside maybe not interchangeable due to different brake manufactures
and (or) different brake type.
 Do not over – fill the master cylinder fluid reservoir.
 Make sure the brake lever and pedal returns freely and completely.
