24-Port 10/100 + 4-Port Gigabit Switch
with WebView
Features
• 24 - 10/100 Switched RJ-45 ports deliver up to 200Mbps of throughput per port
• 4 - 10/100/1000 Switched RJ-45 Gb Uplink Ports (with 2 shared mini-GBIC ports)
• Switching capacity delivers 12.8 Gig non-blocking capacity
• WebView monitoring allows administrators to view the current status and configuration
using their favorite web browser
• Port based and 802.1q based VLANs support up to 256 VLANs
• Port Trunking for up to 8 groups allows you to increase your bandwidth for each uplink or
Server connection
• Port configuration settings for link, speed, auto MDI/MDIX, flow control, and more
• Fully rack-mountable using the included rack-mounting hardware
• Auto MDI/MDIX per port allows for automatic cable detection
• MAC address table supports up to 4K MAC address entries
• Optimal platform to support real-time applications like voice and video by providing features
like IGMP snooping, multiple queues (4) with appropriate scheduling techniques, prioritization
of traffic based on L2/L3 priority, and line rate forwarding mechanisms
• Secure control via SSH for Telnet interface and SSL for HTTP interface
• User/Network security via 802.1x (with RADIUS authentication) and MAC-based filtering
• Containment of storms - Broadcast, Multicast, and Unknown Unicast
• Expandability and availability increased across multiple switches using Link Aggregation
• SNMP and RMON management expand your visibility options
The SRW224G4 provides network
capacity and the ability to grow your
network. Connect server and other
switches at Gigabit Ethernet speed
using the 4 GBit ports and connect
clients at Fast Ethernet speed.
Internet
e.g. via DSL or Cable
Rv042 Router
SRW224G4
Gigabit Ethernet
10/100 Mbit Ethernet
WorkstationsLaptops
Server
Shared Network Printer
