Linksys BEFSR41 Quick Installation Guide

3
In Step 2, you will need the setup
instructions provided by your Internet
Service Provider (ISP). If you do not
have this information, then contact
your ISP before proceeding.
The instructions from your ISP tell you
how to set up your PC for Internet
access. Because you are now using
the Router to share Internet access
among several computers, you will
use the setup information to
configure the Router instead of your
PC.
A Open your PC’s web browser.
Enter http://192.168.1.1 (the
Router’s default local IP
address) in the web browser’s
Address field. Then press the
Enter key.
B A screen will appear and ask
you for a User Name and
Password. Leave the User
Name field empty, and enter
admin (the default) in the
Password field. Then click the
OK button.
C The Router’s Web-based Utility
will appear with the Basic
Setup screen showing.
2
B
A
NOTE:: Make sure your PC’s Ethernet
adapter is set to obtain an IP address
automatically. For more information,
refer to Windows Help.
Configure the Router

Linksys BEFSR41 Specifications

General

Ethernet LAN	Yes
Networking standards	IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Supports ISDN connection	No
Web-based management	-
Ethernet LAN (RJ-45) ports	4
Certification	FCC, CE
Minimum system requirements	TCP/IP\\r Internet Explorer 5.0 / Netscape 6\\r CD-ROM
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Product color	Black, Blue

Weight and Dimensions

Depth	48 mm
Width	186 mm
Height	154 mm
Weight	320 g
