Linksys E3000 Manual

Output Power
You can use these figures to come up with what Tx power would be best for you. As factory lists it at a max
of 20dBm, then a setting of 100mW could be used as 20dBm = 100mW, 17dBm = 50mW, and so on.
2.4GHz output power per TX chain
802.11b: Max. 20.5dBm @ All rates
802.11g: Max. 20.5dBm @ Low rates
Max. 19.5dBm @ High rates
Wireless-N 20MHz: Max. 20.5dBm @ Low rates
Max. 18.5dBm @ High rates
Wireless-N 40MHz: Max. 17.0dBm @ All rates
5GHz output power per TX chain
UNII-1 (5150-5250GHz)
802.11a: Max. 14.0dBm @ All rates
Wireless-N 20MHz: Max. 11.5dBm @ All rates
Wireless-N 40MHz: Max. 12.0dBm @ All rates
UNII-3 (5725-5850GHz)
802.11a: Max. 17.5dBm @ High rates
802.11a: Max. 20.0dBm @ Low rates
Wireless-N 20MHz: Max. 17.5dBm @ High rates
Wireless-N 20MHz: Max. 20.0dBm @ Low rates
Wireless-N 40MHz: Max. 17.5dBm @ High rates
Wireless-N 40MHz: Max. 21.0dBm @ Low rates
Internal PIFA antennas are rated at 3dBi
Initial Flash
See Where do I download firmware? for links.
Linksys_E3000
Initial Flash 2

Linksys E3000 Specifications

General

Ethernet LAN	Yes
Networking standards	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Bandwidth	2.4 GHz
Compatibility	Mac PC
Input current	2 A
Input voltage	12 V
xDSL connection	No
Dimensions (WxDxH)	225 x 180 x 35 mm
USB ports quantity	1
Minimum system requirements	Internet Explorer 6, Safari 3, Firefox 2 Wireless Network-Enabled
Compatible operating systems	Windows XP SP3, Windows Vista SP1, Windows 7 Mac OS X Tiger 10.4.11, Leopard 10.5.8, Snow Leopard 10.6.1
WLAN data transfer rates supported	300 Mbit/s
DHCP client	-
Antennas quantity	3
Ethernet LAN (RJ-45) ports	4
Security algorithms	128-bit WEP, WPA, WPA2
Bundled software	Setup Software User Guide
Certification	FCC, IC, CE, Wi-Fi A/B/G/N
Product color	Black, Blue
LED indicators	Power, USB, Internet, Wireless, Wi-Fi Protected Setup, Ethernet (1-4)
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Weight	452 g
