5-Port and 8-Port 10/100/1000 Gigabit Switches
Chapter 1: Product Overview
Back Panel
The Ethernet network ports are located on the back panel of
the Switch. All ports are auto-negotiating and have automatic
MDI/MDI-X crossover detection.
Back Panel of the 5-Port Switch
1-4 These ports (1, 2, 3, 4) connect the Switch to network
devices, such as computers.
Side Panels
The power port and security slot are located on the side panels of the
Switch.
Side Panel with Power Port
(power) The power port is where you will connect the power
adapter.
