Installing
A. Assembly
1. Connect the power cable (6) to the power port (4) and
connect it to an electrical socket.
3. Plug the telephone cable (5) to the RJ-11 “PHONE 1”
port (1) and connect it to your phone.
B. Connectivity
C. Connecting
(1) RJ-11 “PHONE 1”: to connect to your phone.
(2) RJ-11 “PHONE 2”: (optional) to connect to a second phone.
(3) RJ-45 ETHERNET PORT: for connecting your box to your
router.
(4) Power port: to connect the AC adapter (supplied).
Installing
(1) (2) (3) (4)
Assemble the power adapter (6).
2. Connect the Ethernet cable (2) to the RJ-45 Ethernet
port (3) and connect it to your ADSL box or router.
