Linksys WRT100 User Manual

PRODUCT DATA
RangePlus Wireless Router
The RangePlus Wireless Router is really three devices in one box. First, there’s the
Wireless Access Point, which lets you connect to the network without wires. There’s
also a built-in 4-port full-duplex 10/100 Switch to connect your wired-Ethernet devices
together. Finally, the Router function ties it all together and lets your whole network
share a high-speed cable or DSL Internet connection.
The Access Point built into the Router uses smart antenna technology to achieve
extended range. Unlike ordinary wireless networking technologies that are confused
by signal reflections, the “Multiple In, Multiple Out” (MIMO) technology actually
uses these reflections to increase the range and reduce “dead spots” in the wireless
coverage area. The robust signal travels farther, maintaining wireless connections
much farther than standard Wireless-G.
With MIMO, the farther away you are, the more speed advantage you get. It works
great with standard Wireless-G and -B equipment, but when both ends of the
wireless link are MIMO enabled, the router can increase the throughput even more
by using twice as much radio band. But unlike other speed-enhanced technologies,
the RangePlus Wireless Router can dynamically enable this double-speed mode for
compatible devices, while still connecting to other wireless devices at their respective
fastest speeds.
To help protect your data and privacy, the Router can encode all wireless transmissions
with industrial-strength 256-bit encryption. It can serve as your network’s DHCP
Server, has a powerful SPI firewall to protect your PCs against intruders and most
known Internet attacks, and supports VPN pass-through. Configuration is a snap with
the web browser-based configuration utility.
With the Linksys RangePlus Wireless Router at the center of your home or office
network, you can share a high-speed Internet connection, files, printers, and multi-
player games, and run media-intensive applications at incredible speeds, without the
hassle of stringing wires!
Features
Complies with IEEE 802.11b and
802.11g standards
Expanded wireless coverage
with MIMO technology
Unsurpassed wireless security
with Wi-Fi Protected Access™ 2
(WPA2)
Enhanced Internet security
management functions
including Internet access
policies with time schedules
All LAN ports support auto-
crossover (MDI/MDI-X)—no
need for crossover cables
•
•
•
•
•

Linksys WRT100 Specifications

Power

power voltage	12V
power current	1A

Operating Environment

operating temperature	32 to 104°F (0 to 40°C)
storage temperature	-4 to 140°F (-20 to 60°C)
operating humidity	10 to 85%, Noncondensing
storage humidity	5 to 90%, Noncondensing

Ports & Interfaces

internet port	One 10/100 RJ-45 Port
ethernet ports	Four 10/100 RJ-45 Ports
power port	One Power Port

Antenna Specifications

number of antennas	2
rf power (eirp)	16.5 dBm
antenna gain	1.8 dBi

Weight and Dimensions

dimensions	5.83" x 1.42" x 6.69" (148 x 36 x 170 mm)
weight	0.74 lb (334 g)
