Linksys WTR54GS Quick Installation Guide

2
A Power down your network
devices.
B Locate an optimum location for
the Router. The best place for the
Router is usually at the center of
your wireless network, with line of
sight to all of your mobile stations.
C Connect a standard Ethernet
network cable to the Router’s
Internet port. Then connect the
other end of the network cable to
your broadband modem.
D Connect your computer or
Ethernet device to the Router’s
ethernet port using standard
Ethernet network cabling.
E Power on the broadband
modem.
F Connect the AC power cable to
the Router’s Power port and the
other end into an electrical outlet.
G Power on the PC you wish to use
to configure the Router.
Proceed to Step 2.
C
D
1
Connect the Router
There are two ways to configure the Router. Choose one of the following:
• Run the Setup CD-ROM - It is strongly recommended that you use the
Setup CD-ROM. Insert the Setup CD-ROM into the CD-ROM drive, and
follow the on-screen instructions.
•Use this Quick Installation guide - If you wish, you can use the Router’s
Web-based Utility. Proceed to Step 1 of this Quick Installation.

Linksys WTR54GS Specifications

General

Bandwidth	2.4 GHz
I/O ports	1 x Radio-Ethernet 1 x Ethernet 10Base-T/100Base-TX - RJ-45
xDSL connection	No
Dimensions (WxDxH)	73 x 31 x 107 mm
Maximum data transfer rate	0.054 Gbit/s
Compatible operating systems	Microsoft Windows 98 Second Edition, Microsoft Windows 2000, Microsoft Windows Millennium Edition, Microsoft Windows XP
Data link protocols	Ethernet, IEEE 802.11b, IEEE 802.11g
Minimum RAM	64 MB
Minimum processor	200 MHz
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.3, IEEE 802.3u
Security algorithms	WEP, WPA
MAC address filtering	Yes
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 85 %
Ethernet LAN (RJ-45) ports	2
Certification	FCC, CE, IC-03, Wi-Fi (802.11b, 802.11g), WPA

Weight and Dimensions

Weight	133 g
