A Open your web browser. Enter
http://192.168.16.1 in its
Address field. Press the Enter
key.
B A password request screen will
appear. Leave the User name
field blank, and enter the
default password, admin, in
the Password field. (For added
security, you should later set a
new password, using the
Administration tab’s
Management screen of the
Web-based Utility). Then click
the OK button.
C The Web-based Utility will
appear with the Setup tab
selected. If requested by your
Internet Service Provider (ISP),
complete the Host Name and
Domain Name fields. (These
are usually requested by cable
ISPs.) Otherwise, leave them
blank.
C
Configure the Router
NOTE: Make sure your PC’s Ethernet
adapter is set to obtain an IP address
automatically. For more information,
refer to Windows Help.
B
A
To Next Page
