Chapter 3: Getting to Know the Wireless-G Travel Router with SpeedBooster
The Power Plug and Slide
Wireless-G Travel Router with SpeedBooster
The Power Plug and Slide
Within Most of the Western Hemisphere
The Router’s Power Plug is located on the back panel and the Power Slide is located on the top panel.
Power Plug The Power plug is where you will connect the Router to the electrical outlet.
Power Slide Slide the Power Slide button in one direction to release the power plug and the other
direction for it to return inside the Router.
Outside of the Western Hemisphere
The power cable, provided with the Router, connects to the Power plug. Connect the other end to an electrical
outlet.
Figure 3-2: Western Hemisphere Router
POWER PLUG
POWER SLIDE
Figure 3-3: The Router outside of the
Western Hemisphere
POWER PLUG
