AKURATE Loudspeaker System
Owner’s Manual
AKURATE 242, 225 and 212
English
Tri-wiring or tri-amping
Suggested position of link strips if tri-wiring (i.e. using three pairs of cables
from one power amplifier) or tri-amping (i.e. using one pair of cables from each
of three power amplifier channels).
Important notes on using the link strips
The above configurations are only suggestions; many others are possible. If you
are trying other setups please bear in mind the following points.
●
Never
use the strips to link positive (+) and minus (-) terminals together.
●
Don’t connect more than one strip per terminal.
●
Bass quality will be impaired if you link LOWER BASS and BASS BOOST
together or UPPER BASS, LOWER BASS and BASS BOOST together.
Quad-amping and beyond
Improved audio quality can be obtained by connecting separate power
amplifiers to each pair of speaker terminals (bar the BASS BOOST terminals,
see next page). However, for the best audio performance your AV/hi-fi system
should be converted from running passively to running actively (see
AKTIV
operation
section).
AKURATE 242 and 225 AKURATE 212
TWEETERMID RETEEWT REPUSSSAB REPPULOWER BASSBASS BOOST
ACTIVE
TWEETERMID
R
E
TEEWT R
E
PUSSS
A
B
ACTIVE
Output from
power amplifier
can be
c
onnected to
either of the
two terminals.
Output from
power amplifier
can be
c
onnected to
either of the
two terminals.
Output from
power amplifier
can be
connected to
either of the
two terminals.
Single-wiring
Position of link strips if single-wiring (i.e. using a single pair of cables from one
stereo power amplifier).
Bi-wiring or bi-amping
Suggested position of link strips if bi-wiring (i.e. using two pairs of cables from
one power amplifier) or bi-amping (i.e. using one pair of cables from each of two
power amplifier channels).
AKURATE 242 and 225
AKURATE 212
TWEETERMID RETEEWT REPUSSSAB REPPULOWER BASSBASS BOOST
ACTIVE
TWEETERMID
R
ET
EEW
T
R
EP
USSS
A
B
ACTIVE
Output from
power amplifier
can be
c
onnected to
any of the five
te
rminals.
Output from
power amplifier
can be
connected to
any of the four
te
rminals.
AKURATE 242 and 225 AKURATE 212
TWEETERMID RETEEWT REPUSSSAB REPPULOWER BASSBASS BOOST
TWEETERMID
R
ET
EE
W
T
R
EPUS
S
SA
B
ACTIVE
ACTIVE
Output from
power amplifier
can be
connected to
any of the three
terminals.
Output from
power amplifier
can be
connected to
either of the
two terminals.
Output from
power amplifier
can be
connected to
any of the three
terminals.
