The HELIX grille is special because it mounts directly onto the front facia of the speaker. This avoids the
problems of diffraction produced by conventional grille frames.
To remove the grille cloth, hold the facia with both hands behind the groove in the middle of the vertical
sides and pull forward until it is free from the wooden baffle behind.
To detach the grille cloth, gently pull its elastic edge over one corner of the facia and then slowly and
carefully detach the rest.
To re-assemble, reverse the process and re-attach the moulded facia to the speaker by lining up and
locating the lugs to their inserts on the wooden battle and push home firmly until the facia is flush with the
tweeter.
If the separate, smaller section of the facia shifts during this operation, it should be firmly pushed back
home. To re-fit the grille cloth, reverse the above procedure.
