FUSE/MAINS VOLTAGE SELECTION:
Open the fuse-holder door with a small flat-blade screwdriver. Select the correct
fuse (200mA for 220/240V, 300mA for 100/120V). Fit it into the fuse-holder and
install in the inlet filter.
CAUTION:
Remove the selector barrel BEFORE rotating it.
Set the correct voltage on the voltage selector in the mains input module, and snap
the filter shut.
Tick off the appropriate box next to the right fuse on the LINGO bottom-label and
DISCARD
the two incorrect fuses.
LINGO/LP12 CONVERSION PROCEDURE:
NOTE: This conversion should be carried out by authorised dealers ONLY.
Conversion by unauthorised personnel can be dangerous, and could invalidate the
warranty.
W
ARNING: DISCONNECT THE MAINS SUPPLY FROM THE
TURNTABLE.
Remove the base from the LP12 and remove all the wires from the VALHALLA board
terminal blocks, and remove the old switch assembly. Take out the VALHALLA
board by squeezing the stand-off clips with a pair of long-nose pliers.
Install the interface board (PCAS 101), snapping it onto the same inserts that
held the VALHALLA.
Connect the interconnect lead by pushing on the multi-way connector. Fix this
into the turntable exactly as you would the mains lead.
Push the new switch through the top-plate, and connect the flexible PCB to
the connector as with the VALHALLA.
Connect the motor to the terminal block. Note, the red and blue wires go on
the other way round from the VALHALLA (see printed legend on PCB).
Remove the motor end-cap, spring etc, including thrust-pad if fitted.
Set arm-lead, check set-up etc, and replace base-board.
The turntable is now ready to go.
