CONTROLS AND CONNECTIONS | 11
5
Optical
Audio Out
SOUND
Connect an external digital audio device. Use an Optical cable
(not included) to connect the unit with an amplifier, soundbar
or other audio decoding device for digital audio signal output.
6
LAN
INTERNET
Connect to your broadband modem using an Ethernet cable
(not included).
7
AV IN
You can use this to connect your DVD player. Supports
Standard Definition (SD) picture quality. Requires an AV cable
(not included).
8
Component IN
You can use this to connect your DVD player. Supports Full
High Definition (FHD) picture quality. This also requires a
component cable (not included).
9
Audio IN
SOUND
You can use this to connect Audio to your TV for AV or
Component video inputs. Requires an AV cable (not included).
5 6
1
8
7
9
L - AUDIO - R
Audio IN
