CONTROLS AND CONNECTIONS | 7
Controls and Connections
1. POWER: Turn on or set to
standby.
2. OK: Enter the channel list
menu.
3. CH / CH : Go to the
next or previous channel.
4. LED Display
5. USB Port: Plug in your USB
drive for PVR recording,
Timeshift, playing
multimedia, and for
software updates.
Front view
Rear view
See next page for more info on the connections.
1
6 5 7 8 9 10
4 52 3
