Linx 5900 - Parallel IO Connector; Pin Numbers

Page 31 of 33 FA69388–2 English
Jun 2013
33
How To Use the Parallel I/O Option
Linx 5900 & 7900
3.4 Parallel I/O connector
The Parallel I/O connector is a 25-way D-type connector on the rear panel of the printer (see
Figure 48 on page 32).
3.4.1 Pin numbers
The function of each connector pin is shown in the following table.
PARALLEL I/O CONNECTIONS
Pin no. Function
1OV (for inputs)
2 Input 1
3 (No connection)
4 Input 7
5 Input 5
6 Input 3
7 +24 V supply (for inputs)
80V
9 Output 8
10 Output 6
11 Output 4
12 Output 2
13 +24 V supply (for outputs)
14 Input 2
15 (No connection)
16 Input 8
17 Input 6
18 Input 4
19 Latch input
20 (No connection)
21 0 V (for outputs)
22 Output 7
23 Output 5
24 Output 3
25 Output 1
Table 4. Parallel I/O connections
