Chapter 1: Before you start
FA69315–3 English 9 Linx 5900 & 7900 Quick Start Guide
To remove the black highlight, press the Left arrow key or the Right
arrow key:
Figure 1-8. Remove the highlight
The vertical line in Figure 1-8 is the cursor. The cursor shows your
current position in the box. Press the Left arrow key or the Right arrow
key to move the cursor. Then you can add or insert some characters, or
use the backspace key to delete a single character.
• You can also use the Up and Down arrow keys to increase or decrease
the value in some text boxes. The arrow indicators at the far right of
the box identifies this type of box (see Figure 1-8).
If the printer knows that the information that you entered is incorrect (for
example, an invalid number), the information is shown in red. Some soft
keys or options become unavailable. For example, the name of the OK soft
key in Figure 1-9 is dimmed to show that the key is not available:
Figure 1-9. Incorrect value entered
