Maintaining and servicing your set
Replacing the lamp in your passenger cars
E
ach car car is illuminated by two 12-volt lamps (part no. 600-8352-310). During the
course of normal operations, the lamps may require replacement. To replace a lamp inside
the car, remove the two screws from the underside of the frame. See Figure 11. Once these
screws are removed, you can lift off the roof, remove the expired lamp, and then install the
replacement. Replace the roof and the two screws on the underside of the frame.
Figure 11. Lamp replacement
Lionel part no. 600-8352-310
