Descripon (A):
1. Sunshade
2. 3-point safety belts
3. Bell
4. Handlebars body
5. Handlebars
6. Mug holder
7. Younger child footrest
8. Mudguard
9. Pedal
10. Front wheel
11. Parent’s handle
12. Bow
13. Saddle
14. Bag
15. Rear wheel
16. Main folding key
17. Brake
18. Older child footrest
19. Frame
20. Forks
How to use:
ELEMENTS (B):
Rear wheels (B1) Saddle with a backrest and shank with a nut (B2) Frame with handlebars
and older child footrest (B3) Bow (B4) Bag (B5) Young child footrest (B6) Pedals (B7) Front
wheel (B8) Mug holder (B9) Sunshade (B10) Bell (B11)
How to assemble the tricycle
1. Take the frame out and unfold (B3). If you can hear a „click”, it means it has been
unfolded properly.
2. Assemble rear wheels (B1) in dedicated spots at the back of the frame. If you can hear
a „click”, it means they have been xed properly. Make sure the wheels are secured
properly – try to push them out.
3. Assemble a front wheel (B8) at the front of the frame by inserng it in the dedicated
hole. If you can hear a „click”, it means it has been xed properly.
4. Next aach both pedals (B7) to the front wheel by inserng them into the holes (see:
How to lock pedals). Assemble the footrest (B6) as presented in the photograph – on
the frame, between the handlebars and saddle.
5. Screw the footrest in the frame with the use of a red nut.
6. Fix the mug holder (B9) at the front of the frame. Place the saddle (B2) on the frame
– pull a metal shank through it.
7. Screw in the shank on the other side of the frame with the use of black nut.
8. Put the belt cushion through a bow and join it together.
9. Fix the sunshade (B10) on the saddle brackets which sck out on both sides. In order
to adjust the inclinaon of the sunshade, pull evenly the brackets to the outside and
set the inclinaon angle.
10. Adjust the parent’s handle height by unlocking the red lock buons on both sides of
the frame, and lock them again aer the adjustment
Handle height adjustment
Adjust the height of the bracket for the parent by unlocking the red lock buons on both
sides of the frame, and aer adjusng, lock them again.
