7.0 Video and Image File Size
When recording video it is very important that you are already familiar with the file
size that your computer can store and playback. If you record a continuous video
clip onto a CAMERA GOGGLE's Micro SD/SDHC card, you may not be able to
download or play the video file on your computer because of the large file size.
Also, your media player may not be able to play large HD Videos.
6.2 VIDEO AND STILL IMAGE PLAYBACK ON A TV
1. With the CAMERA GOGGLE turned off, connect the HDMI cable (not included) to
the CAMERA GOGGLE and the HD TV. .
2. Turn on the CAMERA GOGGLE and the camera will automatically start up in video
mode and begin playing the first video on the TV screen.
3. Press the SHUTTER/SELECT button to advance to the next video and press the
POWER/MODE button to go back to the previous video.
4. To switch to the playback of Pictures, press and hold the POWER/MODE button for
3 seconds. You will now be in the picture mode. To advance to the next picture, press
the SHUTTER/SELECT button and to go back to the previous picture, press the
POWER/MODE button.
5. You can toggle between the Picture and Video mode by pressing the POWER/MODE
button for 3 seconds.
6. To turn off, disconnect the HDMI cable from the CAMERA GOGGLE and press and
hold the POWER/MODE button for a few seconds until the camera turns off.
0006 / 0003 00:45:11
00:02:28
File name
Qty of videos per Mode
Mode
Video Time Code
Battery Life
Total Time
TV SCREEN
Video Mode
0006 / 0003
File name
Qty of pics per Mode
Mode
Battery Life
TV SCREEN
Still Image Mode
of Video
0006 / 0003 00:45:11
00:02:28
File name
Qty of videos per Mode
Mode
Video Time Code
Battery Life
Total Time
TV SCREEN
Video Mode
0006 / 0003
File name
Qty of pics per Mode
Mode
Battery Life
TV SCREEN
Still Image Mode
of Video
ENG-15
9.0 CARE AND MAINTENANCE
8.0 FIRMWARE AND PRODUCT UPDATES
Please conduct a FILE SIZE TEST before you use your CAMERA GOGGLE to capture
important images and video. Test various video file sizes to make sure your
computer will be able to store and play the videos that you record. If you have
difficulty in playing back video files smoothly, try taking a shorter video. You may
also try opening the video file with a different media player as not all media players
work the same.
Please read the sample chart below to estimate your file size per minute of
recording time.
Approximate Video File Sizes -
CAMERA GOGGLE
NOTE: Depending on the battery's charge as well as the size of your Micro SD/SDHC
card, you may be able to record a video for an hour or more. It is, however, best to
take short videos. This will make transferring files and playing them back easier.
The camera will split a video file over 1 hour into two files to improve the performance
of the camera.
NOTE: Video file sizes will vary due to the complexity of the scene. The file sizes listed are only estimates.
TIME (min): .5 1 10 20
SIZE OF FILE: 45MB 90MB 900MB 1.7GB
1. Before each use, the goggle should be inspected for any cracks, deformities or damage.
If there is any damage or deformation to the frame, or scratches or damage to the lens
that could obstruct or impair vision, do not use. Replace any damaged parts such as
the lens, strap or face foam prior to use.
TEST
ENG-16
!
Liquid Image will update the software regularly, please refer to the
information on our website and download the newest software.
www.LiquidimageCo.com
2. Do not expose goggle to heat, strong detergents, or chemicals.
3. To clean, rinse the frame with tap water. A mild soap may be utilized on the frame only
when needed. To prevent damaging the lens, only clean the lense with tap water. Dry
with a soft cloth.
4. IMPORTANT: Do not rub lens when wet. When the inner lens surface is wet, it
becomes soft and is more susceptible to scratching. Rubbing the inner lens when it is wet,
may also reduce the effectiveness of the anti-fog coating.
5. To Dry: Gently shake snow and moisture off the lens. Use the micro bag or a soft cloth
to gently blot away moisture or allow lens to air dry. Make sure ventilation ports are clear
of snow or other debris. If wearing the goggle, motion will increase airflow and help to dry
the goggle. Once the lens has completely dried and is at room temperature, use the micro
bag or a soft cloth to remove any smudges.
6. To prevent scratching, do not use paper towels, ski gloves or clothing to clean the lens.
Only use a micro bag or a soft cloth. Abrasive materials may scratch the lens.
7. For optimum life and performance of your lens, store completely dry and in the protective
bag or case. Lens should be kept in a dry environment at room temperature when not in
use. Store the lens away from direct sunlight, or excessive heat or cold.
8. To prevent scratching, do not place lens face down.
10.0 REPLACING LENSES
Wash and thoroughly dry hands prior to removing or inserting the lens. Do not change
the lens while wearing gloves as the glove material may scratch the lens.
10.1 Removing Lens
1. Hold the bottom of the frame and grab the top of the frame from the inside.
2. Gently pull the top of the frame away from the lens.
3. Gently lift the lens out of the sides and bottom of the frame.
10.2 Inserting Lens
1. Insert the lens at the nose of the frame. Take care to align the notch of the lens with
the post in the frame. Gently push the lens onto the post.
2. Continue inserting the lens into the groove along the bottom and sides of the frame.
Make sure to push the lens completely into the groove of the frame.
3. Align the notch on the lens with the post at the top of the frame.
4. Check the lens to make sure that it is correctly set in the frame prior to use.
ENG-17
11.0 CAMERA WARNINGS AND PRECAUTIONS
Never touch the camera connection components that are exposed when the
MEMORY COMPARTMENT OR BATTERY COMPARTMENT are open. There is a
risk of shock if the components in the compartments become wet.
If the CAMERA GOGGLE emits a strange noise, smoke or odor, turn off
immediately and remove the battery.
1. Using the CAMERA GOGGLE in a manner other than what the product use is
intended for may result in injury to you, the product, or other persons.
8. If the inside of the camera gets wet, immediately turn it off and dispose of the
battery. Then dispose of the CAMERA GOGGLE in accordance with laws for
disposing electronics in your country. Using the camera after any internal
compartments have become wet may cause a fire or electric shock.
3. Avoid jolts, drops, collision with other hard objects, or shaking of the CAMERA
GOGGLE. These movements may damage the components.
4. Never open the camera body with a screw driver. There is a risk of shock if you
touch the camera components.
5. Children under 13 years of age should never wear or operate the CAMERA
GOGGLE.
6. Children age 13 to 17 should always have adult supervision with use of this
product. The CAMERA GOGGLE is not a toy and needs to be treated with the same
care as any other digital camera.
7. An adult age 18 or older should always dry the product thoroughly before
performing the battery replacement or before performing the transfer of image and
video files to a computer.
2. This is not a safety Goggle. Only use for intended purposes. The Goggle lens
provides basic protection against wind, dirt, dust, snow and glare. The lens will not
withstand a severe impact. This lens does not protect against hard or sharp objects.
Care should be taken to avoid impact with hard or sharp objects.
GOGGLE.
GOGGLE.
.
ENG-18
!
!
1. Before updating the firmware, make sure the battery level is at least at the 50% level.
Do not try to upload new firmware if the battery level is low as this may cause the camera
to have difficulty uploading firmware in the future.
2. Copy the firmware file to the root directory of the SD card, outside of the main directory
folders. Then, disconnect the USB cable and the camera will automatically shut down.
3. With the camera off, press and hold both the POWER/MODE button and the
SHUTTER/SELECT BUTTON at the same time. Once you hear the camera beep, release
both buttons.
4. The LCD will show “UP” in the LCD screen and then turn off. The new firmware is now installed.
