LISICKI Z-178 - Page 45

42
Z-178
1,65 m
Z-178/2
1,85 m
Z-178/1
1,35 m
Z-178/3
2,10 m
5-178-030-231 1 - - -
5-178-030-231/2 - 1 - -
5-178-030-174 - - 1 -
5-178-030-231/3 - - - 1
14 Widened washer 5-178-030-170 2 2 2 2
16 Bolt M6x16-8.8-B-Fe/Zn8C PN-85/M-82105 49 53 43 58
Bolt M10x20-8.8-B-Fe/Zn8C PN-85/M-82105 19 19 19 -
Bolt M10x25-8.8-B-Fe/Zn8C PN-85/M-82105 - - - 32
21 Nut M6-8-B-Fe/Zn8C PN-86/M-82144 49 53 43 58
23 Nut M10-8-B-Fe/Zn8C PN-86/M-82144 19 19 19 32
24 Washer 6,5 Fe/Zn9 PN-59/M-82030 49 53 43 58
26 Washer 10,5 Fe/Zn9 PN-59/M-82030 19 19 19 32
29 Spring washer 10,2 Fe/Zn9 PN-77/M-82008 19 19 19 32
Part number or standard
19
13
Middle cover
Remarks
Item no.
in Fig.
Part name
Quantity
Table 4. continued.
