respond to the upper control to inform upper control about the error. And the drive keypad
displays CE-XX (XX is the error code) as the warning message. Refer to 11.8.1 Modbus Errors.
Example:
RTU Scheme:
Address
01H
Function
86H
Exception code
02H
CRC CHK Low
C3H
CRC CHK High
A1H
11.7 Modbus Data
The following tables shows all data including command, monitor and broadcast.
 Command Data (Read and write)
Register No.
Definitions
2400H
Retain
2401H
Operation Commands
Bit 0
Stop/Run (0:Stop, 1:Run)
Bit 1
Forward/Reverse (0:Forward, 1:Reverse)
Bit 2
External Fault EF0
Bit 3
Fault Reset
Bit 4
Retain
Bit 5
Retain
Bit 6
Retain
Bit 7
Retain
Bit 8
Multi-Function Terminal 1 (1: ON)
Bit 9
Multi-Function Terminal 2 (1: ON)
Bit 10
Multi-Function Terminal 3 (1: ON)
Bit 11
Multi-Function Terminal 4 (1: ON)
Bit 12
Multi-Function Terminal 5 (1: ON)
Bit 13
Multi-Function Terminal 6 (1: ON)
