Network Architecture
Infrastructure mode
Operation Channel
2.4GHz
11: (Ch. 1-11) – United States
13: (Ch. 1-13) – Europe
14: (Ch. 1-14) – Japan
5GHz
21: USA
19: EU
8: Japan
Frequency Range
802.11bg
2.400 ~ 2.4835 GHz
802.11a
5.15 ~ 5.85 GHz
Transmit Output Power - single chain @ant;
Tolerance: ±2dBm@2.4GHz; ±2.5dBm@5GHz
2.4GHz
802.11b
1Mbps
2Mbps
5.5Mbps
11Mbps
Tgtpwr
(dBm)
14.5
14.5
14.5
14.5
802.11g
6~24Mbps
36Mbps
48Mbps
54Mbps
Tgtpwr
(dBm)
16.5
16
15
13.5
802.11n
HT20
MCS0
MCS1
MCS2
MCS3
MCS4
Tgtpwr
(dBm)
16.5
16.5
16.5
16
16
MCS5
MCS6
MCS7
MCS8
MCS9
15
14
13.5
11.5
802.11n
HT40
MCS0
MCS1
MCS2
MCS3
MCS4
Tgtpwr
(dBm)
15.5
15.5
15.5
15
15
MCS5
MCS6
MCS7
MCS8
MCS9
14
13
12.5
11.5
10.5
5GHz
802.11a
6~24Mbps
36Mbps
48Mbps
54Mbps
Tgtpwr
(dBm)
15.5
14
13
12
802.11n
HT20
MCS0
MCS1
MCS2
MCS3
MCS4
Tgtpwr
(dBm)
15.5
15.5
15.5
15
15
MCS5
MCS6
MCS7
MCS8
MCS9
14
13
12
11
802.11n
HT40
MCS0
MCS1
MCS2
MCS3
MCS4
Tgtpwr
14.5
14.5
14.5
14
14
