LiteOn WCBN3510A - Page 11

Page 11/18
(dBm)
MCS5
MCS6
MCS7
MCS8
MCS9
13
12
11
10
9
802.11ac
VHT80
MCS0
MCS1
MCS2
MCS3
MCS4
Tgtpwr
(dBm)
13.5
13.5
13.5
13
13
MCS5
MCS6
MCS7
MCS8
MCS9
12
11
10
9
8
Receiver Sensitivity
Frequency
Band
Rate
Condition
1x1(1SS)
(dBm)
2x2(1SS)
(dBm)
2.4G
11b-1M
PER < 8%
-95
-97
11b-11M
PER < 8%
-87
-87
11g-6M
PER < 10%
-90
-92
11g-54M
PER < 10%
-73
-75
11ac-VHT20MCS0
PER < 10%
-89.5
-91.5
11ac-VHT20MCS7
PER < 10%
-73
-75
11ac-VHT20MCS8
PER < 10%
-68
-70
11ac-VHT40MCS0
PER < 10%
-87
-89
11ac-VHT40MCS7
PER < 10%
-69.5
-71.5
11ac-VHT40MCS8
PER < 10%
-66.5
-68.5
11ac-VHT40MCS9
PER < 10%
-63
-66
5G
11a-6M
PER < 10%
-87.5
-89.5
11a-54M
PER < 10%
-71
-73
11ac-VHT20MCS0
PER < 10%
-87.5
-89.5
11ac-VHT20MCS7
PER < 10%
-70
-73
11ac-VHT20MCS8
PER < 10%
-66
-69
11ac-VHT40MCS0
PER < 10%
-84.5
-86.5
11ac-VHT40MCS7
PER < 10%
-67
-69
11ac-VHT40MCS9
PER < 10%
-61
-64
11ac-VHT80MCS0
PER < 10%
-81.5
-83.5
11ac-VHT80MCS7
PER < 10%
-65
-67
11ac-VHT80MCS9
PER < 10%
-57
-60
Security
WPS, WPA, WPA2, WEP 64bit & 128bit, IEEE 802.1X, IEEE
802.11i
Common Function
Operating Voltage
3.3 V ±5% I/O supply voltage
Power Consumption
Mode
Average
Peak
2.4G
5G
2.4G
5G
TX
RX
Disable
WiFi+BT
@Wake
up mode
Antenna Type
Triple MHF4 Antenna connectors for WiFi/BT
