Page 10/21
802.11n:
64QAM, 16QAM, QPSK, BPSK
802.11ac:
256QAM, 64QAM, 16QAM, QPSK, BPSK
802.11ax:
1024QAM, 256QAM, 64QAM, 16QAM, QPSK, BPSK
Network Architecture
Infrastructure mode
Operation Channel
2.4GHz
13: (Ch. 1-13) – United States
13: (Ch. 1-13) – Europe
14: (Ch. 1-14) – Japan
5GHz
21: USA
19: EU
8: Japan
6GHz
CH1~CH233
Frequency Range
802.11bg
2.400 ~ 2.4835 GHz
802.11a/ax
5.15 ~ 5.85 GHz
Wi-Fi 6E
5.925~7.125GHz
EVM
CCK < 35%
OFDM < -25dB
MCS0(HT20/40MHz) < -5dB
MCS7(HT20/40MHz) < -28dB
MCS0(VHT20/40/80MHz) < -5dB
MCS7(VHT 20/40/80MHz) < -27dB
MCS8(VHT 20/40/80MHz) < -30dB
MCS9(HE 20/40/80MHz) < -32dB
MCS10(HE 20/40/80/160MHz) < -35dB
MCS11(HE 20/40/80/160MHz) < -35dB
Frequency Offset
2.4GHz
-20ppm < Center Frequency < +20ppm
5GHz
-15ppm < Center Frequency < +15ppm
Transmit Output Power - single chain @ant
Tolerance:
±1.5dBm@2.4GHz; ±2dBm@5GHz
2.4GHz
802.11b
1Mbps
2Mbps
5.5Mbps
11Mbps
Tgtpwr
(dBm)
17
17
17
17
802.11g
6~24Mbps
36Mbps
48Mbps
54Mbps
Tgtpwr
(dBm)
18
15
15
14.5
802.11n
HT20
MCS0
MCS1
MCS2
MCS3
MCS4
