Page 9/21
1.2 PRODUCT SPECIFICATIONS
FUNCTIONAL SPECIFICATIONS
BT Function
Standard
Bluetooth V5.2
Bus Interface
UART
Data Rate
1 Mbps, 2Mbps and Up to 3Mbps
Modulation Scheme
GFSK, π/4-DQPSK and 8-DPSK
Frequency Range
2.402~2.480 GHz
Operating Channel
BR/EDR: 0~78
BLE: 0~39
Transmit Output Power
+4
≤ Output Power ≤ +10dBm; Class I Device
Receiver Sensitivity
BER<0.1% Typical: -90dBm
BLE 1Mbps(PER <30.8%) Typical: -93dBm
BLE 2Mbps(PER <30.8%) Typical: -90dBm
Wi-Fi Function
Standard
IEEE802.11a; IEEE802.11b; IEEE 802.11g; IEEE 802.11n.
IEEE802.11ac; IEEE802.11ax
Bus Interface
PCIe 3.0
Data Rate
802.11a:
54, 48, 36, 24, 18, 12, 9, 6 Mbps
802.11b:
11, 5.5, 2, 1 Mbps
802.11g:
54, 48, 36, 24, 18, 12, 9, 6 Mbps
802.11n:
MCS 0 to 11 for HT20MHz
MCS 0 to 11 for HT40MHz
802.11ac:
MCS 0 to 8 for VHT20MHz
MCS 0 to 9 for VHT40MHz
MCS 0 to 9 for VHT80MHz
802.11ax:
MCS 0 to 11 for HE20MHz
MCS 0 to 11 for HE40MHz
MCS 0 to 11 for HE80MHz
MCS 0 to 11 for HE160MHz
Media Access Control
CSMA/CA with ACK
Modulation
Technique
802.11a:
64QAM, 16QAM, QPSK, BPSK
802.11b:
CCK, DQPSK, DBPSK
802.11g:
64QAM, 16QAM, QPSK, BPSK

LiteOn WCBN814A Specifications

General

Brand	LiteOn
Model	WCBN814A
Category	Control Unit
Language	English
