WCBN814A User Manual
Page 8/21
1.1 PRODUCT FEATURES
Module feature includes:
 Bluetooth V5.2 system
Backwards compatible with BT version of 1.1, 1.2, 2.0, 2.1, 3.0+HS, 4.0LE and 5.0
 Support Bluetooth Class I and Class II power level transmission power without requiring an
external PA
 Dual eSCO and dual A2DP streams
 Supports 2Mbps Bluetooth Low (BLE), BLE long range
 Split ACL support for A2DP true stereo(earbuds)
 Flexible interface Slimbus/PCM/I
2
S for Bluetooth Audio
 Support Wake On Bluetooth
 Operate at ISM frequency Band (2.4/5/6GHz)
 IEEE Standards Support, 802.11a ,802.11b, 802.11g, 802.11n, 802.11ac and 802.11ax
 Supports 2x2 Multi-User Multiple-Input Multiple-Output (MU-MIMO)
 Dual Band Simultaneous (DBS), up to 3Gbps data rate (2x2+2x2 11ax DBS)
 Support for both 20 MHz, and 40 MHz channel width in 2.4GHz, 20 MHz, 40MHz, 80 MHz and
160MHz channel width in 5GHz and 80 MHz and 160MHz channel width in 6GHz band
 Enterprise level security supporting: WPS2.0, WAPI, WPA, WPA2
 Dual-stream IEEE 802.11n support for 40MHz channels provides PHY layer rates up to 300Mbps
 Dual-stream IEEE 802.11ac support for 80MHz channels provides PHY layer rates up to
867Mbps
 Dual-stream IEEE 802.11ax support for 80MHz channels provides PHY layer rates up to
1200Mbps
 Dual-stream IEEE 802.11ax support for 160MHz channels provides PHY layer rates up to
2400Mbps
 Dynamic Frequency Selection (DFS, radar detection)
 Qffloading traffic for minimal host utilization at 802.11ac/ax speeds
 Low-power PCIe (with L1 sub-tate) interface
 Integrated BT/WLAN coexistence
 Support Wake On WLAN
 RoHS compliance
