LiteOn WCBN814A User Manual

WCBN814A User Manual
Page 14/21
11g-6M
PER < 10%
-90
11g-54M
PER < 10%
-73
11n-HT20MCS0
PER < 10%
-87
11n-HT20MCS7
PER < 10%
-70
11n-HT40MCS0
PER < 10%
-84
11n-HT40MCS7
PER < 10%
-67
5G
11a-6M
PER < 10%
-88
11a-54M
PER < 10%
-71
11n-HT20MCS0
PER < 10%
-85
11n-HT20MCS7
PER < 10%
-68
11n-HT40MCS0
PER < 10%
-65
11n-HT40MCS7
PER < 10%
-82
11ac-VHT80MCS0
PER < 10%
-80
11ac-VHT80MCS7
PER < 10%
-63
11ac-VHT80MCS9
PER < 10%
-57
11ax-HE40MCS0
PER < 10%
-83
11ax-HE40MCS9
PER < 10%
-62
11ax-HE40MCS10
PER < 10%
-59
11ax-HE40MCS11
PER < 10%
-56
11ax-HE80MCS0
PER < 10%
-80
11ax-HE80MCS9
PER < 10%
-59
11ax-HE80MCS10
PER < 10%
-56
11ax-HE80MCS11
PER < 10%
-53
11ax-HE160MCS10
PER < 10%
-53
11ax-HE160MCS11
PER < 10%
-50
6G
11ax-HE80MCS10
PER < 10%
-54
11ax-HE80MCS11
PER < 10%
-51
11ax-HE160MCS10
PER < 10%
-51
11ax-HE160MCS11
PER < 10%
-48
Operating Voltage
3.3V ±10% I/O supply voltage
Power Consumption
Mode
Average
(mA)
MAX
(mA)
11n
11ac
11ax
11n
11ac
11ax
TX
907
934
1148
1229
1253
1307
Note: The peak current might reach up to 1.9A
Antenna Type
2x MHF 4 connectors for BT&Wi-Fi

LiteOn WCBN814A Specifications

General

Brand	LiteOn
Model	WCBN814A
Category	Control Unit
Language	English
