Litmor Capsule - Step 5: Place Litmor Capsule on the bracket

󾗱󾗴 󾗱󾗵
STEP 5/7
Place Litmor
TM
Capsule
on the bracket
Carefully push all the wires
through the large opening in the
bracket.
Hold Litmor
TM
Capsule with
both hands as illustrated
on the right and align
its bottom with the
mounting bracket.
1
2
55
o
Rotate Litmor
TM
Capsule clockwise to its lock position.
Make sure it's tight connected to the bracket.
3
